36″ Fire Pit Series Linear Trough Pan With T-Burner, Match Lit Ignition – HPC

These burners are exclusively made by HPC- the unique V-shaped pan design saves on media versus a standard rectangle bowl pan. The T-burner and pan are constructed with #304 stainless steel. The 24″, 36″ and 48″ pans are made with 18 ga stainless steel, while the larger 60″, 72″ and 96″ pans are made of 16 ga stainless steel. All kits include trough pan, T-burner, burner brackets and center bracket. Warping of pan lip while hot is possible – could cause lip to not sit flush on surface. Please recess lip below enclosure top to hide any warping.

About HPC:

HPC is on the cutting edge of outdoor gas fire pit technology and offers a wide variety of burners to fit the need of any construction or do-it-yourself project. All HPC fire pit rings have staggered burner ports for a more natural-looking flame pattern and presence. Both stainless steel and cold rolled steel burners are available, and both feature ports that are drilled, not punched, for optimal quality; the burner hub is raised above the concentric rings to reduce the risk of water in the valve or gas line.

FPS/TRGH36 Kit Specification:

• Fuel: Natural Gas, Liquid Propane (LP)
• Ignition: Match Lit
• Power Required: Not Required
• BTU (Max): 75k
• Pan Size: 36″
• Burner Size: 36″
• Pan Type: Linear Trough Pan
• Burner Type: T-Burner
• Series: FPS Series

Owners Manual – HPC Linear Trough Pan With T-Burner

---
