Name: A Myriad of Choices: 30X12" Rectangle Pan H-Burner Fire Pit Insert - HPC in Diverse Styles and Hues.
SKU: TOR-30X12SS
Price: 96.99 USD
Availability: InStock

Sale!

30X12" Rectangle Pan H-Burner Fire Pit Insert - HPC

30X12" Rectangle Pan H-Burner Fire Pit Insert - HPC - Image 2

30X12" Rectangle Pan H-Burner Fire Pit Insert - HPC - Image 3

30X12" Rectangle Pan H-Burner Fire Pit Insert - HPC - Image 4

30X12" Rectangle Pan H-Burner Fire Pit Insert - HPC - Image 5

Original price was: $340.00.Current price is: $96.99.

SKU: TOR-30X12SS Categories: Build Your Own Fire Pit, Fire Pit Rings & Burners

Buy quality, buy with us.
7 Days of Hassle-Free Returns
Multiple payment options for secure shopping with SSL
Guaranteed High Quality

Rectangle Burners

This part number utilizes not only the H-Burner but also the rectangle bowl pan and brackets making this a quick-fire pit drop in insert. These low profile H-burners are constructed of sturdy 304 stainless steel and are used in vented gas fireplace. The gas inlet (3/8″MPT) can be either left or right-hand application, holes can be pointed up for exceptional flame with glass media, holes down if adding sand to quiet gas.

Now with a Lifetime warranty on all Burners!

Model # / Description / BTU

24X12SS-H / 24X12″ pan, 18X6″ burner, 75k
30X12SS-H / 30X12″ pan, 24X6″ burner, 100k
36X14SS-H / 36X14″ pan, 30X8″ burner, 125k
42X14SS-H / 42X14″ pan, 36X8″ burner, 150k
54X16SS-H / 54X16″ pan, 48X10″ burner, 200k
66X16SS-H / 66X16″ pan, 60X10″ burner, 200k
78X16SS-H / 78X16″ pan, 72X10″ burner, 300k
90X16SS-H / 90X16″ pan, 84X10″ burner, 350k

Features

Raised Hub Design
Stagger Port Burner Holes
#304 Stainless Steel
LP Kits- Tuned Gas Air Mixer Included
Includes pan, burner and brackets

HPC offers H-Burners in many sizes designed specifically for use in outdoor fire pits. These burners use our raised hub design for shedding of water. Hub is a robust 1/2″ coupler. The tubing is 1/2″ #304 stainless steel with holes drilled at 30 degrees for inward flame pattern.

Spec Sheets

HPC Fire Pit Linear Trough Spec Sheet | PDF | Download

Manual’s & PDF’s

Spec Sheets

HPC Fire Pit Linear Trough Spec Sheet | PDF | Download

Additional Product Specifications

Length:

30″
Burner Shape:

H-Burner
Burner Shape:

Rectangular
Width:

12″
Type:

Burner & Pan Combo
Ignition Type:

Match Lit
Material:

Stainless Steel
Flame Type:

Standard Flame

Legal Disclaimers and Warnings

Please Read: Product packaging, owner’s manuals, installation instructions, and/or operating instructions may include more information than what is shown on our website. The content on our site is intended to be used for reference purposes only. Please fully read all included manuals and documentation before installing or using this product.

Prop 65 WARNING for California Residents: this product may contain lead and lead chemical(s) known to the state of California to cause birth defects, cancer, or other reproductive harm.
